Hikvision IP Video Intercom Kit

General:

• Power Consumption: 10 W
• Working Temperature: -40° C to +60° C (-40° F to 140° F)
• Working Humidity: 10% to 95%
• Dimension (L X W X D): 200 mm × 140 mm × 15.1 mm (7.9″ × 5.5″ × 0.6″)
• Weight: 683 g (with packaging) 355 g (without packaging)
• IP Protection Level: IP65
• Memory: 128 MB
• Dimensions(L × W × H): 98 mm × 99.8 mm × 43.9 mm (3.86″ × 3.93″ × 1.73″)

Audio Parameters:

• Audio Compression Rate: 64 Kbps
• Audio Compression Standard: G.711 U
• Audio Input: Built-in omnidirectional microphone
• Audio Output: Built-in loudspeaker
• Audio Quality: Noise suppression and echo cancellation

Video Parameters:

• Video Compression Standard: H.264
• Resolution: Main Stream: 1920 × 1080,Sub Stream: 720 × 480

Audio Parameters:

• Audio Input: Built-in Omnidirectional Microphone
• Audio Output: Built-in Loudspeaker(More than 85 dB within 20 cm )
• Audio Compression Standard: G.711 U
• Audio Compression Rate: 64 Kbps
• Audio Quality: Noise Suppression and Echo Cancellation

Alarm Parameters:

• Alarm Input: Tampering Alarm

System Parameters:

• Operation System: Embedded Linux operation system

Device Interfaces:

• I/O Input: 4
• I/O Output: 2

System Parameters:

• Processor: Embedded MCU Processor
• Operation System: Embedded Linux Operation System

Network Parameters:

• Network Protocol: TCP/IP, SIP, RTSP

Network Parameters:

• Ethernet:10/100 Mbps Self-Adaptive Ethernet
• Network Protocol: TCP/IP, RTSP

Light Supplement:

• Light Supplement Mode: IR Supplement

• 1 x DS-KD8003-IME1/Surface
• 1 x DS-KH6320-WTE1
• 1 x 4 Port Standard PoE Switch
• 1 x 16GB TF Card
• European Power Supply Adaptor
